How to Wire Cable TV

Cable signals are now a widely utilized method for receiving TV signals. The signals come from a cable outlet mounted in the wall of your home, rather than an antenna. Signals are provided to the cable outlet by your local cable TV company. You can make or change your own in-house cable routing to achieve a variety of service arrangements, including providing signal to multiple TVs. Use this guide to learn how to wire cable TV.

Steps

  1. Decide if you want to install a modem in your cable TV system.A modem provides Internet service through your cable system.
  2. Choose an in-line amplifier.In-line amplifiers are available at electronic stores. Use an in-line amplifier if your splitter has more than 2 outlets or if you intend to expand the cable wiring in the future.
  3. Place the in-line amplifier.The amplifier does not need to be mounted or visible when the wiring is complete. Leave it on the floor with the cable in an area without foot traffic. The amplifier must be accessible to perform the wiring.
  4. Connect the in-line signal amplifier.Connect a cable from the cable outlet connector of the house to the inlet of the amplifier. The cables must be RG6 coaxial cable predetermined with F connectors on both ends. These types of cables are available at electronic stores.
  5. Choose the signal splitter.Each splitter will have 1 in connector and 2 or more out connectors. Choose a splitter that had sufficient out connectors to separately provide signal to each TV that you plan to use, as well as to a modem. Splitters are available at electronic stores.
  6. Place the signal splitter.The splitter need not be mounted. The splitter need not be visible in the completed wiring. The splitter must be accessible to perform the wiring.
  7. Connect the signal splitter.Connect a cable from the out connector of the signal amplifier to the in connector of the splitter.
  8. Place the modem.The modem does not need to be mounted or readily seen. Place the modem in the desk or table area containing the computer that will be used to access the Internet. It must be in an area that is accessible so you can make adjustments to the modem settings as necessary.
  9. Connect the modem.Connect a cable from 1 of the out connections of the splitter to the in connector of the modem.
  10. Connect the TVs.Connect a separate splitter output to the in terminal of the cable control box of each TV that is to be provided with signal.

Community Q&A

Search
  • Question
    Do I need to have basic cable for the signal amplifier to work?
    wikiHow Contributor
    Community Answer
    Yes, you do.
    Thanks!
Ask a Question
200 characters left
Include your email address to get a message when this question is answered.
  • Consider the physical placement of your system elements before buying the interconnecting cables. Pre-terminated coaxial RG6 cable is available in various lengths. Choose cable lengths between physical parts of the network that will not leave large loops of rolled up excess cable between them.

Warnings

  • Do not use more than 1 splitter in the system because your signal will be degraded. Buy 1 splitter that has sufficient outlets for your needs, rather than trying to stack up splitters.
  • Do not place cable across floor surfaces where people may walk. The cable may be damaged by the pressure of being stepped on and will present a trip hazard.
